Backlapping
DANGER
ToAvoidPersonalInjuryorDeath
Neverplacehandsorfeetinthereelareawhiletheengineis
running.Stayawayfromthecuttingreelswhenbacklapping.
Whenbacklapping,runengineatidlespeedonly.
Whilebacklapping,thereelsmaystallandthenrestart.
Donotattempttorestartreelsbyhandorfoot.
Donotadjustreelswhiletheengineisrunning.
Ifareelstalls,stopenginebeforeattemptingtoclearthereel.
Reelmotorsareconnectedinseries:rotatingonemotorcauses
rotationinothermotors.
InstructionsandproceduresonbacklappingareavailableintheTractionUnit
Operator'sManualandtheT oroGeneralServiceTrainingBook,ReelMower
Basics(partno.09168SL).
g251598
Figure330
1.T opsurface
3.T opangle
2.Removeburr(withoutdullingsharpcorner)
4.Frontangle
Forabettercuttingedge,runaleacrossthefrontfaceofthebedknifewhenthe
lappingoperationiscompleted.Thiswillremoveanyburrsorroughedgesthat
mayhavebuiltuponthecuttingedge.
Reelmaster
®
5410/5510/5610Series
Page9–19
CuttingUnit:ServiceandRepairs
15216SLRevC
