Toro 03606A Service Manual

TestingtheHydraulicSystem
Themosteffectiveproceduretoisolatetheproblemsinthehydraulicsystemisto
usehydraulictestequipment,suchaspressuregaugesandowmetersinthe
circuitsduringdifferentoperationalchecks;refertoSpecialT ools(page6–44).
WARNING
Openingthehydraulicsystemwithoutreleasingpressurefromthe
systemwillcausethehydraulicuidtoescape,causingpossible
injury.
Beforeyoudisconnectthehydrauliccomponentsorworkonthe
hydraulicsystem,releasethepressureinthesystem;referto
ReleasingPressurefromtheHydraulicSystem(page6–8).
WARNING
Hydraulicuidescapingunderpressurecanpenetrateskinand
causeinjury.
•Keepyourbodyandhandsawayfrompin-holeleaksornozzles
thatejecthydraulicuidunderhighpressure.
•Donotuseyourhandstosearchforleaks;useapieceofpaper
orcardboard.
•Hydraulicuidescapingunderpressurecanhavesufcientforce
topenetratetheskinandcauseseriousinjury.
•Ifhydraulicuidisinjectedintoyourskin,theuiddamageto
yourbodymustbesurgicallyremovedwithinafewhoursbya
doctorfamiliarwiththisformofinjuryorgangrenemayresult.
CAUTION
Failingtousegaugeshavingtherecommendedpressure(kPa/psi)
ratingcoulddamagethegaugeandcausepersonalinjuryfrom
contactwithhot,leakinghydraulicuid.
Usegaugeswiththerecommendedpressureratingaslistedinthe
testprocedures.
IMPORTANT
Beforeperformingthehydraulictests,checkallobviousareas,such
asuidsupply,lter,bindinglinkages,loosefasteners,orimproper
adjustmentsbeforeyouassumethatahydrauliccomponentisthe
sourceoftheproblem.
HydraulicSystem:TestingtheHydraulicSystem
Page6–56
Reelmaster
®
5410/5510/5610Series
15216SLRevC
