Adjustments
CAUTION
Donotworkonthegroomerwiththeenginerunning.
Alwaysshutofftheengine,removethekeyfromthekeyswitch,
andwaitforallmachinemovementtostopbeforeworkingonthe
groomer.
Note:TheInstallationInstructionsforthegroomerhasdetailedinformation
regardingassemblyandadjustment.UsethoseInstructionsalongwiththis
ServiceManualwhenservicingthegroomer.
AdjustingtheHeight/DepthoftheGroomer
Note:Groomingisperformedabovethesoillevel.Whenadjustingthegroomer
height/depth,thegroomerbladesshouldnotpenetratethesoil.
1.Parkthemachineonacleanandlevelsurface,lowerthecuttingunits
completelytotheground,shutofftheengine,settheparkingbrake,and
removethekeyfromthekeyswitch.
2.Ensurethattherollersarecleanandthecuttingunitissettothedesired
height-of-cut;refertotheCuttingUnitOperatorsManual.
g215685
Figure373
1.Groomerheightadjuster3.Gaugebarassembly
2.Quick-uplever
4.Groomerheight
3.Positionthegroomerreeltothelowered,groomingposition(Figure373).
Note:Improperorover-aggressiveuseofthegroomer(e.g.,toodeeportoo
frequentgrooming)maycauseunnecessarystressontheturfleadingto
severeturfdamage.Usethegroomercautiously.
Note:Usethegaugebarassembly(referto(page))todeterminethe
groomerheight.
4.Ononeendofthegroomerreel,measurethedistancefromthelowesttipof
thegroomerbladetotheworkingsurface.Turnthegroomerheightadjuster
toraiseorlowerthegroomerbladetiptothedesiredheight(Figure373).
BeltDrivenGroomer(Optional):Adjustments
Page10–4
Reelmaster
®
5410/5510/5610Series
15216SLRevC
