RemovingtheAirCleanerAssembly

1.Parkmachineonalevelsurface,lowercuttingunits,stopengine,engage

parkingbrakeandremovekeyfromthekeyswitch.Raiseandsupporthood.

2.Removeaircleanercomponentsasnecessary(Figure43).

3.RefertoTractionUnitOperator’sManualforaircleanerserviceand

maintenanceprocedures.

InstallingtheAirCleanerAssembly

IMPORTANT

Anyleaksintheairltersystemwillallowdirtintoengineand

willcauseseriousenginedamage.Ensurethatallaircleaner

componentsareingoodconditionandareproperlysecuredduring

assembly.

1.Assembleaircleanersystem(Figure43).

g229321

Figure44

1.Aircleanerassembly3.Adapter

2.Indicator4.Evacuatorvalve

A.Ifserviceindicator(item6inFigure43)andadapterwereremovedfrom

aircleanerhousing,applythreadsealanttoadapterthreadsbefore

installingadapterandindicatortohousing.Installadaptersothatthe

groovesinadapterhexandadapterlterelementareinstalledtoward

serviceindicator(Figure44).Torquetheindicatorto1.4to1.6N∙m(12

to15in-lb).

B.Ensurethatevacuatorvalveonaircleanerassemblyispointeddown

afterassembly.

Reelmaster

5410/5510/5610Series

Page5–7

KubotaGasolineEngine:ServiceandRepairs

15216SLRevC
