HeightAdjusterAssembly

g215599

Figure391

1.Washer-headscrew6.Upperramp

11.Jamnut(2each)

2.Detentspring7.Externalsnapring12.Balljointrod

3.Groomeradjuster

8.Lowerramp

13.Shoulderbolt

4.Flatwasher9.Flange-headscrew

14.Groomerplate(leftdrive)

5.Bushing

10.Compressionspring

Note:Thegroomerreeldriveislocatedontheoppositesideofthecuttingunit

fromthecuttingreelhydraulicmotor.Figure391showsthecomponentsused

whenthegroomerreeldriveisontheleftsideofthecuttingunit.

DisassemblingtheHeightAdjusterAssembly

1.Parkthemachineonacleanandlevelsurface,lowerthecuttingunits

completelytotheground,shutofftheengine,settheparkingbrake,and

removethekeyfromthekeyswitch.

2.DisassembletheheightadjusterasshowninFigure391.

3.Cleanallthecomponentsandinspectforwearordamage.Replaceallthe

componentsthatarewornordamaged.

Reelmaster

5410/5510/5610Series

Page10–23

BeltDrivenGroomer(Optional):ServiceandRepairs

15216SLRevC
