ServiceandRepairs
HydraulicReelMotor
IMPORTANT
Whenperformingthemaintenanceproceduresonthecuttingunits,
carefullypositionthecuttingunitreelmotorstopreventdamageto
themotorsorhydraulichoses.
RemovingtheHydraulicReelMotor
1.Parkthemachineonacleanandlevelsurface,lowerthecuttingunits
completelytotheground,shutofftheengine,settheparkingbrake,and
removethekeyfromthekeyswitch.
g214396
Figure327
Cuttingunitwithcastironsideplate
1.Hydraulicreelmotor
3.Reliefvent
2.Bolt(2each)4.Greasetting
2.Loosenthe2bolts(item2inFigure327)thatsecurethehydraulicreelmotor
tothecuttingunitsideplate.Rotatethemotorclockwiseandremovethe
motorfromthecuttingunit.
3.Placeaprotectiveplasticcap(referto(page))intotheholeinthecuttingunit
sideplatetopreventunwantedmaterialenteringintothereelbearingarea.
InstallingtheHydraulicReelMotor
Checkthereelinsertsplinesforwear.Replacetheinsertsifnecessary;referto
ReelAssemblyService(cuttingunitswithpaintedsideplates)(page9–33)or
(page).
Reelmaster
®
5410/5510/5610Series
Page9–17
CuttingUnit:ServiceandRepairs
15216SLRevC
