CrossTrax™AWDControlManifoldAssembly

g186174

Figure161

1.Hydraulichose(4each)

6.Hydraulictube

11.O-ring(2each)

2.Straighttting(7each)7.O-ring(7each)

12.Framebracket

3.AWDcontrolmanifold8.O-ring(7each)13.Bolt(3each)

4.Hydraulictube

9.Dustcap(2each)14.Lockwasher(3each)

5.Hydraulictube

10.Diagnostictting(2each)15.Spacer(3each)

RemovingtheCrossTraxAWDControlManifoldAssembly

1.Parkthemachineonalevelsurface,lowerthecuttingunits,shutoffthe

engine,settheparkingbrake,andremovethekeyfromthekeyswitch.

CAUTION

Beforeopeningthehydraulicsystem,operateallthehydraulic

controlstoreleasesystempressureandavoidinjuryfromthe

pressurizedhydraulicuid;refertoReleasingPressurefromthe

HydraulicSystem(page6–8).

2.ReadtheGeneralPrecautionsforRemovingandInstallingtheHydraulic

SystemComponents(page6–145).

3.LocatetheCrossTraxAWDcontrolmanifoldthatisattachedtothebracket

atrearoftheframe.

4.Forassemblypurposes,labelallthehydraulicconnections.Cleanthe

hydraulicconnectionsbeforelooseningthehydrauliclines.

Reelmaster

5410/5510/5610Series

Page6–185

HydraulicSystem:ServiceandRepairs

15216SLRevC
