ServicingtheRoller

g195108

Figure351

1.Rollertube

5.Outerseal

2.Rollershaft

6.Bearinglocknut

3.Innerseal

7.Greasetting

4.Bearing

DisassemblingtheRoller

1.Removethebearinglocknutfromeachendoftherollershaft.

2.Looselysecuretherollerassemblyinabenchviseandlightlytaponeendof

therollershaftuntiltheoutersealsandbearingareremovedfromopposite

endoftherollertube.Removethesecondsetofoutersealsandbearing

fromtherollertubebytappingonoppositeendoftheshaft.Removethe

shaftfromtherollertube.

3.Carefullyremovetheinnersealfrombothendsoftherollertube,ensurethat

youdonotdamagethetubesurfaces.

4.Discardthesealsandbearingsthatwereremoved.

5.Cleantherollershaftandallsurfacesontheinsideoftherollertube.Inspect

componentsforwearordamage.Also,carefullyinspecttheseatingsurface

andthreadsofthebearinglocknuts.Replaceallthecomponentsthatwere

damaged.

Reelmaster

5410/5510/5610Series

Page9–47

CuttingUnit:ServiceandRepairs

15216SLRevC
