BedknifeReplacementandGrinding

RemovingtheBedknife

1.Removethebedbarfromthecuttingunit;refertoBedbarAssembly(page

9–20).

g214675

Figure333

1.Screw(8each)

3.Bedbar

2.Bedknife

2.Removethescrewsfromthebedbarwithasocketwrenchandbedknife

screwtool(referto(page)).Discardthescrews.Removethebedknifefrom

thebedbar(Figure333).

3.RefertoGrindingtheBedknife(page9–24)foradditionalinformation.

InstallingtheBedknife

1.Useascrapertoremoveallrust,scaleandcorrosionfromthebedbar

surface.Lightlyoilthebedbarsurfacebeforeinstallingthebedknife.

2.Ensurethatthescrewthreadsinthebedbar(5/16-18UNC-2A)areclean.

IMPORTANT

Donotuseanimpactwrenchtotightenthescrewsintothebedbar.

3.Usenewscrewstosecurebedknifetobedbar.Applyanti-seizelubricantto

thethreadsofnewscrews.Donotapplyanti-seizelubricanttothetaper

ofthescrewheads.

4.Installallscrewsbutdonottighten.

Reelmaster

5410/5510/5610Series

Page9–23

CuttingUnit:ServiceandRepairs

15216SLRevC
