InstallingtheBedknife(continued)
g251663
Figure334
5.Usingatorquewrenchandbedknifescrewtool,tightenthe2outerscrewsto
1N∙m(10in-lb).
6.Workingfromthecenterofthebedknifetowardeachend,tightenscrews
from23to28N∙m(200to250in-lb).
7.Afterinstallingthebedknifetothebedbar,grindthebedknife.
GrindingtheBedknife
g207291
Figure335
1.T opangle
4.Frontsurface
2.T opsurface
5.Frontangle
3.Removeburr(withoutdullingsharpcorner)
BedknifeGrindingSpecications
Bedknife
LipHeight
ServiceLimit
TopAngleFrontAngle
EdgeMax®LowHOC
PremiumLowHOC
StandardLowHOC
5°
ExtendedEdgeMax®LowHOC
ExtendedLowHOC
10°
10°
EdgeMax®StandardHOC5°
StandardStandardHOC
HeavyDutyStandardHOC
4.8mm(0.190
inch)
10°
5°
CuttingUnit:ServiceandRepairs
Page9–24
Reelmaster
®
5410/5510/5610Series
15216SLRevC
