GrindingtheBedknife(continued)
Sincetherecanbevariationsinthemountingsurfaceofthebedbar,anew
bedknifewillnotbeperfectlyatafteritisinstalledtothebedbar.Becauseof
this,itisnecessarytogrindanewbedknifeafterinstallingittothebedbar.
Followthebedknifegrindingspecicationsprovidedandgrindonlyenoughto
ensurethatthetopsurfaceofthebedknifeistrue;refertoBedknifeGrinding
Specications(page9–24)andFigure335.
g251664
Figure336
LipHeightServiceLimit
IMPORTANT
DoNotgrindthebedknifebelowit’sservicelimit;refertoFigure336.
Operatingthecuttingunitwiththebedknifebelowtheservicelimit
mayresultinpoorafter−cutappearanceandreducethestructural
integrityofthebedknifeforimpacts.
Whengrindingthebedknife,becarefultonotoverheatthebedknife.Remove
smallamountsofmaterialwitheachpassofthegrinder.Also,cleananddress
grindingstoneoftenduringthegrindingprocess.
Note:EdgeMax®bedknivesareextremelyhard.Usingadiamondgrinding
wheelisrecommendedtopreventoverheatingordamagingthebedknifeedge
whilegrinding.
Becausethetopgrindangleonbedknivesiscriticalforedgeretention,and
thereforeafter-cutappearance,Torohasdevelopedspecialservicetoolsfor
accuratelymeasuringthetopgrindangleonallbedknives;refertothe(page).
Note:Somebedkniveswereproducedwitha5°topangle.Usea10°topangle
whenregrindingallbedknives.
1.UseToroGeneralServiceTrainingBook,ReelMowerBasics(ToroPart
No.09168SL),andgrindermanufacturer’sinstructionsforbedknifegrinding
information.
Reelmaster
®
5410/5510/5610Series
Page9–25
CuttingUnit:ServiceandRepairs
15216SLRevC
