HeadlightSwitch
g190997
Figure245
1.Controlarm
2.Headlightswitch
Theheadlightswitchislocatedontheoperatorsideofthecontrolarm(Figure
245).Thisrockerswitchallowstheheadlightstobeturnedonandoff.
TestingtheHeadlightSwitch
1.Parkthemachineonalevelsurface,lowerthecuttingunits,settheparking
brake,andshutofftheengine.
2.Removetheleftcontrolarmcovertogetaccesstotheheadlightswitch;refer
toDisassemblingtheControlArm(page8–23).
3.EnsurethatthekeyswitchisintheOFFposition.Disconnectthewireharness
electricalconnectorfromtheheadlightswitch.
g223017
Figure246
4.TheheadlightswitchterminalsareidentiedinFigure246andthecircuitryof
theswitchisshownintheCircuitLogicT able(page7–72).Withtheuseofa
multimeter(ohmssetting),testtheswitchfunctionstodetermineifcontinuity
existsbetweenthevariousterminalsforeachswitchposition.Checkthe
continuitybetweentheswitchterminals.
CircuitLogicTable
SwitchPositionNormalCircuitsOtherCircuits
ON
2+35+6
OFF
2+15+4
Note:Theheadlightswitchterminals1,4,5,and6arenotusedonthe
Reelmastermachines.
5.Replacetheheadlightswitchiftestingdeterminesthattheswitchisdamaged.
ElectricalSystem:TestingtheElectricalComponents
Page7–72
Reelmaster
®
5410/5510/5610Series
15216SLRevC
