TestingtheFuelPumpCapacity(continued)

4.Disconnectthefuelpumpdischargehosefromtheinletttingofthe

fuel/waterseparator.

5.Placethedisconnectedendofthepumpdischargehoseintoalarge,

graduatedcylindersufcientenoughtocollect0.9L(32oz).

IMPORTANT

Whentestingthefuelpumpoutput,donotturnthekeyswitchto

theSTARTposition.

6.TurnthekeyswitchtotheONpositionandcollectthefuelinthegraduated

cylinder.Allowthepumptorunfor30secondsandthenturntheswitchto

theOFFposition.

Note:Theamountoffuelpumpedin30secondsmustbeapproximately

350ml(11.8oz).

7.Replacethefuelpumpifoutputspecicationisnotmet.

IMPORTANT

Ifthefuelpumpisreplaced,ensurethatreplacementpumpisthe

correctpumpforyourReelmasterbyusingyourPartsCatalog.If

incorrectpumpisused,thefuelsystemdamagecanoccur.

8.Connectthefuelpumpdischargehosetothefuel/waterseparator.Ensureto

securethehosewiththehoseclamp.

9.Primethefuelsystem;refertoPrimingtheFuelSystem(page4–23).

FuelPumpSpecications

PumpCapacity700ml/minute(23.5oz/minute)

Pressure

22.8kPa(3.3psi)

MaximumCurrentDraw

0.9A

10.Lowerthehoodandsecureitwiththelatches.

Reelmaster

5410/5510/5610Series

Page7–109

ElectricalSystem:TestingtheElectricalComponents

15216SLRevC
