EngineFaults(continued)
StartingProblems(continued)
Problem
PossibleCauses
Nothinghappenswhenyouattempttostartthe
engine.TheInfoCenterdisplayoperateswith
thekeyswitchintheRUNposition.
Note:Anoperatoradvisoryisdisplayedonthe
InfoCenteriftheinterlockswitchesforengine
startarenotfunctioning.UsetheInfoCenter
displaytoassistwithidentifyingtheproblem.
•ThetractionpedalisnotintheNEUTRAL
position.
•Theoperatorseatisunoccupiedorthe
parkingbrakeisnotapplied.
•Thecuttingunitsareengaged(thereel
engageswitchisintheONpositionoritis
damaged).
•Thejoystickisnotinthecenterposition.
•Thebatteryisdischargedordamaged.
•Thebatterycablesarelooseorcorroded.
•Thegroundconnectionislooseorcorroded.
•Thetractionneutralswitchisoutof
adjustment.
•Thetractionneutralswitchorcircuitwiring
isdamaged.
•Theseatswitchorcircuitwiringisdamaged.
•Theparkingbrakeswitchorcircuitwiringis
damaged.
•Thejoystickswitchorcircuitwiringis
damaged.
•Thekeyswitchorcircuitwiringisdamaged.
•Thestartrelayorcircuitwiringisdamaged.
•Themainpowerrelayorcircuitwiring
isdamaged(headlightsandpowerpoint
inoperativeaswell).
•TheTECfuses(in-line2Aorfuseblock7.5
A)aredamaged.
•Thefusiblelinkatbatteryisopen(machine
withdieselengine).
•Thefusiblelinkharnessattheenginestarter
motorisdamaged.
•Thewiringtostartcircuitcomponentsis
loose,corroded,ordamaged;refertothe
ElectricalSchematicandWireHarness
Drawings/DiagramsinAppendixA(pageA–1).
•Thestartersolenoidisdamaged.
•Thetemperaturesenderorcircuitwiringis
damaged.
•TheTECisdamaged.
•Thestartermotorisdamaged.
•TheengineECUorcircuitwiringisdamaged.
ElectricalSystem:Troubleshooting
Page7–38
Reelmaster
®
5410/5510/5610Series
15216SLRevC
