Toro 03606A Service Manual

PlasticPlug
ToroPartNo.94-2703(for7
inchreels)
ToroPartNo.2410-30(for5
inchreels)
Thiscapisusedforplacement
intothecuttingunitside
platewhenthecuttingreel
motorisremoved.Itprevents
dirtandunwantedmaterial
fromenteringthecuttingreel
bearingarea.
CuttingUnitKickstand
ToroPartNo.119-8010-03
Thecuttingunitkickstandisused
topropuptherearofthecutting
unitduringservice.Useofthis
toolstabilizesthecuttingunitand
preventsthebedbaradjusting
screwsfromrestingonthework
surface.
SplineInsertTool
ToroPartNo.TOR4112(8tooth
for5inchreels)
ToroPartNo.TOR4074(9tooth
for7inchreels)
Usethesplineinserttoolfor
rotatingthecuttingreelwhenmotor
isremoved.Alsousethistoolfor
installationofthreadedinsertsinto
thecuttingreelshaft.
RollerBearingandSealInstallationTools
ToroPartNo.115-0803
Thistoolkitisusedtoassemblethe
cuttingunitrollers.Thetoolsinthis
kitarealsoavailableindividuallyas
follows:
1.Innersealtool:115-0852
2.Bearinginstallationwasher:
107-8133
3.Bearing/outersealtool:
115-0853
CuttingUnit:SpecialTools
Page9–6
Reelmaster
®
5410/5510/5610Series
15216SLRevC
