ReelAssemblyInstallation(continued)
g252671
Figure344
1.RHsideplate2.LHsideplate
4.Applyathincoatofantiseizelubricanttothereelbearingboreofeachside
plate.
5.Makesurethatatwirespring(item14)isinstalledintoLHsideplate.
CAUTION
Contactwiththereel,bedknifeorothercuttingunitpartscanresult
inpersonalinjury.Useheavygloveswheninstallingthecuttingreel.
6.CarefullyslidetheRHendofthecuttingreelassembly(nogrooveinreel
shaftoronfaceofthreadedinsert)intotheRHsideplate.Makesurethat
bearingisfullyseatedintosideplate.
7.SlidetheLHsideplateontothecuttingreelassembly.
8.InstallshoulderboltsandangenutsthatsecuretheLHsideplatetothe
cuttingunitframe.Tightentheshoulderboltsfrom37to44N∙m(27to33
ft‐ ‐
‐
lbs).
9.ApplyLoctite#243(orequivalent)tothreadsofangeheadscrewthat
securesframespacerandcarrierframetoLHsideplate.Installscrewand
tightenfrom37to44N∙m(27to33ft‐ ‐
‐
lbs).Aftertighteningscrew,checkthe
clearancebetweenthecarrierframeandsideplate.Ifclearanceismorethan
0.065”(1.6mm),removeangeheadscrewandpositionshim(s)between
carrierframeandsideplatesothatclearanceislessthan0.065”(1.6mm).
Makesurethatthecarrierframepivotsfreelyafterassembly.
10.InstallcapscrewandatwasherthatsecurereargrassshieldtoLHside
plate.T orquescrewfrom20to25N∙m(15to19ft‐ ‐
‐
lbs).
11.Installtherearroller;refertoInstallingtheRearRoller(page9–45).
12.Installthefrontroller;refertoInstallingtheFrontRoller(page9–43).
CuttingUnit:ServiceandRepairs
Page9–38
Reelmaster
®
5410/5510/5610Series
15216SLRevC
