E6582062
11-3 11. Table of parameters
1
3
9
10
11
FMOd 0004
Frequency
command
select 1
0: -
1: Terminal RR
2: Terminal RX
3: Terminal II
4: Terminal AI4 (option)
5: Terminal AI5 (option)
6 - 9: -
10: Touch wheel 1 (power off
or press OK to save)
11: Touch wheel 2 (press OK
to save)
12: Sr0
13,14: -
15: Terminal Up/Down
frequency
16: Pulse train
17: High resolution pulse
train (option)
18,19: -
20: Embedded Ethernet
21: RS485 communication
(connector 1)
22: RS485 communication
(connector 2)
23: Communication option
-- 1N
[4. 3. 1]
[4. 4. 1]
[5. 2. 1]
[5. 4. 1]
[7. 3. 2]
[7. 3. 3]
[7. 3. 4]
Pt 0015 V/f Pattern
0: V/f constant
1: Variable torque
2: Automatic torque boost
3: Vector control 1
4: Energy savings
5: Dynamic energy savings
(for fan and pump)
6: PM motor control
7: V/f 5-point setting
8: -
9: Vector control 2
(speed / torque)
10: PG feedback control
11: PG feedback vector
control (speed / torque)
12: -
-- 0N
[5. 3. 4]
[5. 3. 5]
[6. 23. 1]
[6. 23. 2]
vb 0016
Manual
torque boost
1
0.00 - 30.00 % *1 Y [5. 3. 6]
vL 0014
Base
frequency 1
15.0 - 590.0 Hz
50.0 /
60.0 *2
Y [5. 2. 2]
vLv 0409
Base
frequency
voltage 1
240V class: 50-330V
480V class: 50-660V
V *2 Y [5. 2. 2]
FH 0011
Maximum
frequency
30.0 - 590.0 Hz *2 N [5. 2. 3]
UL 0012
Upper limit
frequency
0.0 - FH Hz
50.0 /
60.0 *2
Y [5. 2. 3]
LL 0013
Lower limit
frequency
0.0 - UL Hz 0.0 Y
[5. 2. 3]
[6. 9]
ACC 0009
Acceleration
time 1
0.0 - 6000 (600.0) s *1 Y
[5. 2. 4]
[5. 3. 3]
[6. 27. 2]
Title
Communication
No.
Parameter
name
Adjustment range Unit
Minimum
setting unit
(Panel/
Communication
)
Default
setting
Write
during
running
*6
User
setting
Reference
