Toshiba TOSVERT VF-AS3 User Manual

E6582062
11. Table of parameters 11-4
1
9
11
dEC 0010
Deceleration
time 1
0.0 - 6000 (600.0) s *1 Y
[5. 2. 4]
[5. 3. 3]
[6. 27. 2]
Sr0 0030
Preset speed
0
LL - UL Hz 0.0 Y [5. 3. 7]
Sr1 0018
Preset speed
1
LL - UL Hz 0.0 Y
[4. 4. 3]
[5. 3. 7]
[6. 28]
Sr2 0019
Preset speed
2
LL - UL Hz 0.0 Y
Sr3 0020
Preset speed
3
LL - UL Hz 0.0 Y
Sr4 0021
Preset speed
4
LL - UL Hz 0.0 Y
[5. 3. 7]
[6. 28]
Sr5 0022
Preset speed
5
LL - UL Hz 0.0 Y
Sr6 0023
Preset speed
6
LL - UL Hz 0.0 Y
Sr7 0024
Preset speed
7
LL - UL Hz 0.0 Y
FPId 0025
PID1 set
value
F368 - F367 Hz 0.0 Y
[5. 3. 8]
[6. 21]
Fr 0008
Panel Fwd/
Rev run
select
0: Fwd run
1: Rev run
2: Fwd run (switchable F/R
by panel)
3: Rev run (switchable F/R
by panel)
-- 0Y
[4. 3. 2]
[5. 3. 9]
tHrA 0031
Motor
overload
protection
current 1
Depending on capacity *1 A *1 Y [5. 2. 5]
OLM 0017
Motor
overload
protection
characteristic
0: Standard motor, OL2, No
stall
1: Standard motor, OL2, Stall
2: Standard motor, No OL2
trip, No stall
3: Standard motor, No OL2
trip, Stall
4: Constant torque motor,
OL2, No stall
5: Constant torque motor,
OL2, Stall
6: Constant torque motor, No
OL2 trip, No stall
7: Constant torque motor, No
OL2 trip, Stall
- - 0 Y [5. 2. 5]
FMSL 0005
Terminal FM
function
0 - 162 *3 - - 0 Y
[5. 2. 6]
FM 0006
Terminal FM
adjustment
----Y
Title
Communication
No.
Parameter
name
Adjustment range Unit
Minimum
setting unit
(Panel/
Communication )
Default
setting
Write
during
running
*6
User
setting
Reference

Toshiba TOSVERT VF-AS3 Specifications

General

Model	TOSVERT VF-AS3
Category	Inverter
Overload Capacity	150% for 60 seconds
Cooling Method	Forced Air Cooling
Control Method	V/f control, Sensorless vector control
Braking Unit	Built-in
Communication Protocols	Modbus RTU, DeviceNet, Profibus DP
Protection Functions	Overcurrent, Overvoltage, Undervoltage, Overheat, Ground Fault
Enclosure	IP20
Operating Temperature	-10°C to +50°C
Humidity	5-95% (non-condensing)
Altitude	Up to 1000m
