Program 76-Num-Tm : LCR – Routing Table
76-Num-Tm Rou Ta
00 00 0 00 0 00
Num = 01~60 Tm = Time Schedule (A, B, C)
Setting Value
IP Value Default Item Description
01,02 00~23 00 Start Hour of this Route Table
03,04 00~23 00 End Hour of this Route Table
05 0~8 0 1
st
priority trunk group for dialing
06,07 00~99 00 Modify table for the 1
st
priority trunk group
08 0~8 0 2
nd
priority trunk group for dialing
09,10 00~99 00 Modify table for the 2
nd
priority trunk group
11 0~8 0 3
rd
priority trunk group for dialing
12,13 00~99 00 Modify table for the 3
rd
priority trunk group
14 0~8 0 4
th
priority trunk group for dialing
15,16 00~99 00 Modify table for the 4
th
priority trunk group
General:
This program assigns different time schedules, the priority to select different trunk groups and the modifying tables for
the routing tables.
Description:
20 routing tables can be used for normal operation plus 20 for the first holiday and another 20 for the second holiday.
3 time schedules can be assigned for each routing table.
4 priority trunk groups can be assigned for each routing table. (If there is no trunk group assigned here, system will
use Dial 9 trunk group instead.)
4 modifying tables can be assigned for each routing table.
For weekly holiday 1, system will refer to 76-(21~40).
For weekly holiday 2, system will refer to 76-(41~60).
Time Schedule A & B: _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _
Time schedule C does not have the Starting/Ending hour setting. Only priority trunk groups and modifying tables need
to be assigned. . If only 1 Time Zone is to be used then use Time Schedule C which will automatically cover 24 hours if
Schedule A and B are blank.
Related system Programming: 05-13-07. 05-13-08, 36, 41-ST-04, 75, 76, 77, 78-st-01, 78-st-02
Starting Hour
1
st
priority TK group (1~8)
1
st
priority modifying table (00~99)
2
nd
priority TK group (1~8)
2
nd
priority modifying table
3
rd
priority TK group
3
rd
priority modifying table
4th priority modifying table
4th priority TK group (1~8)
To Next Page
