04. Dial 9 trunk group/ SLT Port as MOH Source
When a station selects a trunk line by dialing 9, the system finds an available trunk according to the dial 9 group
assignment. If a trunk is not in a stations assigned dial 9 group then the station will not be able to make outgoing calls
on that trunk.
IP Value Value Description
41-stn-04 0 use “Dial [87] trunk group” as “Dial 9 trunk group”. (see mode 46-ST-01).
That is, Dial 9 can access the “Dial [87] trunk group”. Using this setting can
extend Dial 9 trunk groups from 8 to 16.
41-stn-04 1 search in the 1st tk group
41-stn-04 2 search in the 2nd tk group
.. ……
41-stn-04 8 search in the 8
th
tk group
If the Extension is an SLT port, it can be used as an additional MOH input allowing individual tenants to each have
their own Message on Hold. The port is set to type 7 in Mode 43-port-02 then in Mode 41-slt-04 user can allocate
which trunk group will use this port as a MOH source. The current drawn from the SLT port MUST be limited to no
more than 10ma to prevent damage. A line isolator will achieve this.
IP Value Value Description
41-stn-04 0 All Trunk groups
41-stn-04 1-8 Trunk group 1 to 8
Related System Programming Mode: 36, 38, 41-ST-04, 46-ST-01
05. Toll plan - Day
This parameter assigns the toll plan to be used by the station in day mode.
Refer to Mode 18 for Toll plan details.
06. Toll plan - Night
This parameter assigns the toll plan to be used by the station in night mode.
Refer to Mode 18 for Toll plan details.
07. Port Number
This is for checking only, the system will automatically show the correct port number. It is not possible for the user to
change or remove this parameter.
In the G1E, the port number consists of 2 digits
IP Value Value Description
41-stn-07 11~18 station ports on the G1E-MBU
41-stn-07 21~28 station ports on the 1
st
G1E-STU or G1E-SLU card
41-stn-07 31~38 station ports on the 2
nd
G1E-STU or G1E-SLU card
41-stn-07 41~44 SLT station ports on MBU
