Program 29-tk-IP : Trunk Specifications – 2
29-tk-IP TK SPEC
0 0 0 2 0 0 0 0
Tk=Trunk No. (01-12), IP = Item Pointer (01-08)
Value for each Item
IP Value Default Item Description
01 0-1 0= 0 db Trunk Receive Gain
02 0-8 0=Disable ACD-1 Function Enable
03 0~9 0= 0db Trunk Transmit Gain
04 0-8 2= Frequency 2 Set Ring Frequency (DK Handsets)
05 0-9 0=All Stations Allow Audible Ring for Incoming Calls
06 0-1 0=Disable Polarity Reverse Detection. Individual Trunk-outgoing.
07 0-9 0=Disable CO Delayed Ring Timer to Hunting Group
08 0-9 0=The 1
st
Hunting Group CO Delayed Ring Overflow Hunting Group
General:
This program permits each trunk line to be assigned different parameters.
01. Trunk Receive Gain
This parameter adjusts the TKU interface receive gain to adapt to different CO loop resistance. For long loop situation
where the receive audio may be low. This parameter will allow receive loudness to be boosted.
IP \ Value 0 1 2 3 4 5 6 7 8 9 unit
29-01-01 0 1 2 3 4 5 6 7 8 9 db
02. ACD-1 Function Enable
This parameter enables or disables the ACD-1 function for each trunk individually and is able to select whether ACD-1
operates in Day or Night or Both Modes.
IP Value Day Time Night Time
29-tk-02 0 Disable ACD function Disable ACD function
29-tk-02 1 Disable ACD function Enable ACD function (Note 1)
29-tk-02 2 Disable ACD function Enable ACD function (Note 2)
29-tk-02 3 Enable ACD function (Note 1) Disable ACD function
29-tk-02 4 Enable ACD function (Note 1) Enable ACD function (Note 1)
29-tk-02 5 Enable ACD function (Note 1) Enable ACD function (Note 2)
29-tk-02 6 Enable ACD function (Note 2) Disable ACD function
29-tk-02 7 Enable ACD function (Note 2) Enable ACD function (Note 1)
29-tk-02 8 Enable ACD function (Note 2) Enable ACD function (Note 2)
Note
1: Enable ACD-1 function only when all ring assigned stations are busy.
2: Enable ACD-1 function when Program 05-09-06 timer has elapsed even if ring assigned stations are idle.
03. Trunk Transmit Gain
This parameter adjusts the TKU interface’s transmit gain to adapt to different CO loop resistance. For long loop
situation where the transmit audio may be low. This parameter will allow transmit loudness to be boosted.
IP \ Value 0 1 2 3 4 5 6 7 8 9 unit
29-01-03 0 1 2 3 4 5 6 7 8 9 db
