TransTel Communications G1E+ - Program 39-IP: Sensor Assignments

I
Program 39-IP : Sensor Assignments
39-STN-IP Sensor
FN S
STN = Station No. ( 00 / 000 / 0000) 2/3/4 digits
sensor on the motherboard
39-STN-IP Sensor
FN S
STN = ACP station number
Sensor on the ACP
IP Value Item Description
39-STN-01 00-18 Function No.
39-STN-02 0-2 Sensor Type
Description:
The G1E-MBU and each ACP provides 1 Sensor.
FN= Function No. S=Sensor Type
Each Sensor can be assigned to one of the following 18 functions.
FN Function
00 No Operation
01 Fire Alarm
02 Break Alarm
03 Door Phone 1
04 Reserved for future use
05 Security feature
06-18 Reserved for future use
The valid sensor types for sensor on the motherboard:
S Item Description
0 Disable Sensor function
1 Normally Open for night
2 Normally Closed for night
3 Normally Open day
4 Normally Closed Day
5 Normally open Day/Night
6 Normally Closed Day/night
The valid sensor types for sensor on the ACP:
Value Item Description
0 Disable Sensor function
1 Normally Open
2 Normally Closed
