Program 05-02-IP : System Timing Parameters – 02
05-02-IP SYS PAR
5 5 1 6 4 1 2 6
IP=Item Pointer (01-08)
Value for each item
IP Value Default Item Description
01 0-9 5= 15 Sec. SLT Dial Tone Timeout
02 0-9 5= 15 Sec. SLT Inter-Digit Timeout
03 1-9 1= 10 Sec. Auto Redial Access Time – PSTN Lines
04 0-9 6= 1000 ms. SLT Release Signal Time
05 0-9 4= 400 ms. PSTN Lines Flash Time - Key Phone & Analog Phone
06 0-9 1= 80 ms. SLT Hold Signal Time
07 0-9 2= 240 ms. Ring On Time
08 0-9 6= 6 Sec. Ring Off Time
01. SLT Dial Tone Timeout
This parameter is for SLT (Single Line Telephone). If a key of SLT is not pressed before this assigned timer expires
when Dial Tone is given, a Busy Tone will be heard.
IP \ Value 0 1 2 3 4 5 6 7 8 9 Unit
05-02-01 0 2 4 6 8 15 30 60 120 254 Sec.
02. SLT Inter-Digit Timeout
This parameter is for SLT (Single Line Telephone). If the interval between digits dialed exceeds this assigned timer, a
Busy Tone will be given.
IP \ Value 0 1 2 3 4 5 6 7 8 9 Unit
05-02-02 0 2 4 6 8 15 30 60 120 254 Sec.
03. Auto Redial Access Time – PSTN Lines
This parameter sets the waiting timer after system redial the telephone number in Auto Redial feature. If the call is not
answered before this timer expires, system will hang up and wait for the Auto Redial Pause Time – Program 05-05-
08, and then try to redial again. ISDN lines will hang up immediately if the called number is busy. Refer to Program 05-
05-07 Auto Redial Trials for number of redial attempts
IP \ Value 1 2 3 4 5 6 7 8 9 Unit
05-02-03 10 20 30 40 50 60 70 80 90 Sec.
04. SLT Release Signal Time
The time duration of depressing the hook switch of an SLT longer than this timer and then system will recognize it as a
Release Signal. Please note that the system will take it as a Hold signal if less than this timer but longer than the SLT
Hold Signal Timer (Program 05-02-06).
IP \ Value 0 1 2 3 4 5 6 7 8 9 Unit
