Program 43-cn-IP : Port Specifications
43-pn-IP Port
nnnn 0 1 0 00 02
pn = Port No. (2 digits) IP = Item Pointer (01-06)
Value for each Item
pn = Port Number (11-56)
11~18: station port on G1E-MBU
21~28: station port on the 1
st
G1E-STU card.
31~38: station port on the 2
nd
G1E-STU or G1E-SLU card.
41~44: SLT ports on G1E-MBU.
IP Value Default Item Description
01 nnnn System Station Number (2 to 4 digits)
02 0-9 System Equipment Type
03 1-9 1=1 DSS Soft key Plan
04 0 0= Reserved
05 00-50 00= disabled Voice Mail Box Capacity
06 00-90 01=1 Minute Maximum Voice Mail Message Length
General:
This program permits each port to be assigned different parameters and station numbers.
Description:
01. Station Number
Use this setting to assign station numbers for the Flexible Numbering Plan. The allowed number range is 10-69, 100-
699. 1000-6999. If it is necessary to use digits 7 or 8 as part of the station numbering scheme then Mode 05-08-05
must first be set to 8 to prevent confusion between control codes/programming digits and Station numbers.
02. Equipment Type
IP Value Value Description
43-pn-02 0 None connected
43-pn-02
1 Digital Phone without LCD
43-pn-02
2 Digital Phone with LCD
43-pn-02
3 Not used
43-pn-02
4 Single Line Telephone
43-pn-02
5 DSS
43-pn-02
6 Dual port
43-pn-02
7 SLT Port used as MOH input.
43-pn-02
8 Voice Mail Port
43-pn-02
9 ISDN Device
43-pn-02
D Door phone/ACP
43-pn-02
- SLT Paging port (press [FLASH] for entering -
43-pn-02
T Fax Port (press [MSG] for entering T)
1) Types 0 to 5 and d are recognized by the system automatically.
2) Type 6 allows an SLT port to be paired to a Digital Extension providing a pseudo Hybrid port. Once set the SLT
phone can be given the same extension number as a Digital Extension and when the number is called both Phones
will ring. Either phone can answer or once one answers then a call to the same number will show busy. The call can
