TransTel Communications G1E+ - Program 06-IP: Relay Assignment

Program 06-IP : Relay Assignment
06-St-01 Relay
00
St= Station Number
Value for each Item
St Item Value Relay Description
000 00-06, 10, 11-18 Relay of Motherboard (Optional)
xxx 00-06, 10, 11-18 Relay of ACP (extension: xxx)
Description:
Relays on the Motherboard and ACP are dry-contact type relays. The relay provides no power, only a switching
function.
The maximum limit for the voltage and current for the relay contacts is 24Vdc or 90Vac at 1 A.
They are only designed for low voltage control circuits. All Relays are Normally Open contacts and will close on
activation of the function for which they have been programmed.
When the St is 000, it means the relay on the motherboard. When the St is a valid station number, it is the relay on the
ACP corresponding to that station number..
Assign the required Relays to one of the following functions.
Item Value Function
00 No Operation
01 Music On Hold
02 Reserved for future use
03 Reserved for future use
04 Trunk loud bell
05 Station loud bell
06 System Alarm
10 All Paging [#0]
11 External zone page Group - 1 [#31]
12 External zone page Group - 2 [#32]
13 External zone page Group - 3 [#33]
14 External zone page Group - 4 [#34]
15 External zone page Group - 5 [#35]
16 External zone page Group - 6 [#36]
17 External zone page Group - 7 [#37]
18 External zone page Group - 8 [#38]
