05. Key Phone Toll Override Prevention
If the setting is Disable, after accessing a line a user will be able to use a DTMF generator directly to the network
rather than the DTMF signal generated within the KSU. The result of this is that Toll restrictions can be over-ridden.
If the setting is Enable, then no audio will be sent from the handset until 3 digits are received by the KSU from the key
station dial pad preventing Toll restrictions being overridden. This parameter will be automatically disabled on any lines
which are set to Pulse Dial.
IP \ Value 0 1
05-07-05 Disable Enable
06. SMDR Digit Mask
If the setting is "0", then the full length of the telephone number will be output to the SMDR. If setting is n, only the first
n digits will be output to the SMDR.
n = 1 to 9
07. CO Line Guard Timer
This timer offers a pause time when a line is released before It can be accessed again.
IP \ Value 0 1 2 3 4 5 6 7 8 9 unit
05-07-07 0 1 2 3 4 5 6 7 8 9 sec.
08. Reserved
