SMDR OUTPUT DATA FORMAT - With CLI Output
ST. TK S TELEPHONE NUMBER Account MM/DD START DURATION RING UNIT
112 01 001188629645752 12345678 10/02 08:35 00:02'35" 00012
112 02 DDI Num:94150112 10/02 08:45 00:10'20" 00'10"
03 CLI NoAns:294176288 10/02 12:00 00:00'00" 00'35"
111 05 CLI Num: 294150100 10/02 12:35 00:00'05" 00'05"
05 DDI NoAns:94150112 10/02 12:37 00:00'00" 00'27"
CASE
1 Outgoing call. All information remains as before.
2
Incoming call on an ISDN system. The number displayed is the In dial number dialed by the calling party.
The system can be programmed on a station by station basis to select whether calls to that station will
display the In dial number dialed or the CLI information of the incoming caller
3
An incoming call rang for 35 seconds and no one answered. The CLI number of the calling station is
displayed.
4
An incoming call on line 5 (ISDN) was answered by station 111. The SMDR displayed the CLI number
(294150100) of the calling party. The system can be programmed on a station by station basis to select
whether calls to that station will display the In dial number dialed or the CLI information of the incoming
caller. The number 94150100 is the pilot number of the In dial group.
5
An incoming call rang for 27 seconds and no one answered. The In dial number the calling station dialed
is displayed.
Note: Maximum of 25 SMDR records can be stored in the system temporarily.
