turck TBEN-L Series User Manual

EtherNet/IP™
Hans Turck GmbH & Co. KG | T +49 208 4952-0 | F +49 208 4952-264 | more@turck.com | www.turck.com
76
 Configuration Assembly (TBEN-Lx-16DXP/TBEN-L4-16DXN)
Byte Bit 7 Bit 6 Bit 5 Bit 4 Bit 3 Bit 2 Bit 1 Bit 0
Module configuration data, see Module Configuration Data, page 77
0 to 8
Reserved
9
----
LED
behavior
(PWR) at
V2
under-
voltage
Eth 2
Port
Setup
Eth 1
Port
Setup
Quick
Connect
Parameters of the I/O channels, see Parameters for I/O Channels, page 43
Byte Bit 7 Bit 6 Bit 5 Bit 4 Bit 3 Bit 2 Bit 1 Bit 0
10
Reserved
11
12
Inv. DI7 Inv. DI6 Inv. DI5 Inv. DI4 Inv. DI3 Inv. DI2 Inv. DI1 Inv. DI0
13
Inv. DI15 Inv. DI14 Inv. DI13 Inv. DI12 Inv. DI11 Inv. DI10 Inv. DI9 Inv. DI8
14
SRO7 SRO6 SRO5 SRO4 SRO3 SRO2 SRO1 SRO0
15
SRO15 SRO14 SRO13 SRO12 SRO11 SRO10 SRO9 SRO8
16
EN DO7 EN DO6 EN DO5 EN DO4 EN DO3 EN DO2 EN DO1 EN DO0
17
EN DO15 EN DO14 EN DO13 EN DO12 EN DO11 EN DO10 EN DO9 EN DO8
18
Reserved
19
Pulse stretching input 0
20
Pulse stretching input 1
21
Pulse stretching input 2
22
Pulse stretching input 3
23
Pulse stretching input 4
24
Pulse stretching input 5
25
Pulse stretching input 6
26
Pulse stretching input 7
27
Pulse stretching input 8
28
Pulse stretching input 9
29
Pulse stretching input 10
30
Pulse stretching input 11
31
Pulse stretching input 12
32
Pulse stretching input 13
33
Pulse stretching input 14
34
Pulse stretching input 15
