Uniden BCD396XT User Manual

BC346XTSearchFor < UnidenMan4 < TWiki
Set Step
Select the number of kHz between each channel. Choose 5.0, 6.25, 7.5, 8.33, 10.0, 12.5,
15.0, 20.0, 25.0, 50.0 or 100.0 kHz. Select Auto to use the default step for this band.
Set C-Ch Only
If you set C-Ch Only Mode to On, the scanner will only search for control channel data.
If it detects such data it will stop on the control channel and display channel activity for
the found system. For Motorola systems, it will try to follow voice channel traffic using
the Motorola Band Plan you select in the next setting. It will also display the name of the
found system if the system's ID matches a known system.
Set MOT BandPlan
If this custom search is a Motorola system, you need to select a band plan, just like you
do when you program a Motorola system for scanning. See Edit Band Plan for more
information.
Search with Scan
Search and Store
Search a stored system and save the frequency information of any active channels.
Set Search Key
The scanner has three one-touch search keys (number keys 1 , 2 , and 3 ) that you can
assign to any saved search range.
1. Select the search key you want to program ( Search Key 1 through Search Key
3 ).
2. Select the search range you want to assign to this key. The search range can be a
service search, a custom search, a tone-out search, or a band scope search.
3. Press YES to confirm the selection.
Once you assign a search range to a key, you can start the search just by pressing and
file:///C|/Documents%20and%20Settings/POpitz/My%20D...ts/temp/CDImage_090515/Manual/BC346XTSearchFor.html (4 of 5)5/26/2009 11:16:46 AM

Uniden BCD396XT Specifications

General

Belt clip	Yes

Weight and Dimensions

Weight	907 g
Dimensions (WxDxH)	51 x 25 x 1152 mm
