Modulation icon This icon displays the modulation type of the current
channel: AM, FM, NFM, FMB, or WFM.
Priority icon The current channel is set as a priority channel.
Priority scan icon (PRI) Steady: Priority scan is turned on.
Blinking: Priority Plus scan is turned on.
REP icon The Repeater Find feature is turned on.
Signal level icon This icon displays the strength of the current signal;
the icon ranges from zero bars (no signal) to five bars
(strong signal).
System number line (Sx:) In Scan mode: The system/site Quick Key numbers
(SQK) of any unlocked systems or sites are displayed
on this line. The SQK number of the system or site that
is currently being scanned blinks. For SQK numbers
above 9, the tens digit replaces the X in the icon; the
ones digits are shown on this line.
In Hold mode: This line displays the SQK number of
the current system or site only. For SQK numbers
above 9, the tens digit replaces the X in the icon; the
ones digit is displayed on this line.
In Service Search mode: The icon SCR replaces the
System numbers if the broadcast screen feature is
turned on.
Weather alert icon Weather Alert Priority scan is turned on.
Special displays
In some operation modes, the display can be very different from the main display. These
modes also have 2 or 3 different displays you can cycle through.
● Band Scope mode display
● Hold mode displays
● GPS mode display
