Reversed (filled) icon:
● Steady: Close call DND mode is on.
● Blinking: Close call DND mode is on, and the scanner
has detected a close call signal.
Function icon Steady: You tapped the FUNCTION key; the scanner will
remember the FUNCTION + key combination for the next 3
seconds.
Blinking: You pressed & held the FUNCTION key: the
scanner will remember the FUNCTION + key combination
until you tap FUNCTION again.
Group number line
(GRP)
In Scan mode: The group Quick Key numbers (GQK) of any
unlocked groups in the current system or site are displayed on
this line. The GQK number of the group that is currently being
scanned blinks.
In Hold mode: This line displays the GQK number of the
current group only.
In Custom Search mode: The numbers of any programmed
search ranges are display on this line. The number of the
custom range that is currently being searched blinks.
Hold icon The scanner is in Hold mode.
IFX icon You switched to the intermediate frequency (IF exchange).
This icon appears above the System Number Line in the
Function mode. (Not illustrated.)
GPS icon GPS: The scanner is receiving data from the GPS device.
Lockout icon The current channel is locked out.
Modulation icon This icon displays the modulation type of the current channel:
AM, FM, NFM, FMB, or WFM.
Priority icon The current channel is set as a priority channel.
Priority scan icon (PRI) Steady: Priority scan is turned on.
Blinking: Priority Plus scan is turned on.
