Uniden BCD396XT User Manual

SingleFrequencyP25TrunkedSystems < UnidenMan4 < TWiki
2. Go to the Edit Group menu and select New Group .
3. If you need to change any of the channel group properties, you can do that now.
Unless a property is Required , you can operate the system without changing the
default settings.
Channel group properties
(All of these options can be found by selecting the group name under the Edit Group
menu. If necessary, the sub-menu and the exact option name are listed beside each
property.)
Required None
Recommended
Name (Edit Name)
Quick key (Set Quick Key)
Optional
Location information (Set LocationInfo)
Lockout (Set Lockout)
Available
operations
Delete Group
Create a channel
Each trunked system can contain up to 500 channels in each group.
1. On the Edit Group menu, select the channel group you just created.
2. Go to the Edit Channel menu and select New Channel .
3. Input the Talk Group ID (TGID) for this channel.
4. If you need to change any of the channel properties, you can do that now. Unless
a property is Required , you can operate the system without changing the default
settings.
Channel properties
(All of these options can be found by selecting the channel name under the Edit Channel
file:///C|/Documents%20and%20Settings/POpitz/My%20Do..._090515/Manual/SingleFrequencyP25TrunkedSystems.html (4 of 5)5/26/2009 11:11:55 AM

Uniden BCD396XT Specifications

General

Belt clip	Yes

Weight and Dimensions

Weight	907 g
Dimensions (WxDxH)	51 x 25 x 1152 mm
