Individual phone configuration 193
Network information
This information overview in the user area of the service menu provides you with
information about the IP address or name of the phone and the HTML address
of the WBM interface. It also provides real-time data about the network activity
of the phone.
N Press the key shown.
Select and confirm the option shown.
Select and confirm the option shown.
if nec.j Enter and confirm the user password.
Select and confirm the option shown. You can browse the following overview:
Adresse des Telefons: Name or number of telephone.
Web-Adresse: HTTP address of the web interface. This address is specified in
the address line of the Internet browser and is used to call up the web interface
of the phone in the browser.
IP address: Displays the IP address or name that was assigned to the phone in
the network.
Globale IPv6-Adresse: Displays the global IPv6 address
Lokale IPv6-Adresse: Displays the local IPv6 address
LAN/PC-RX: The network or PC interface data packets received are illustrated
dynamically as columns.
LAN/PC-TX: The network or PC interface data packets sent are illustrated
dynamically as columns.
LAN/PC autonegotiated: [Yes|No]: Displays whether the network or PC
interface data transfer rate is set to automatic (
YES) or manual (No).
LAN/PC information: [10|100|1000] Mbit/s: Data transfer rate of the network
or PC interface. If an interface is not in use,
Link down is displayed.
