O P E R ATIN G A N D O PE R AT I O N
111
W L 3 0
Fig. 47
Switch for loader lift
arm vibration damp-
ing
Loader lift arm damper activation
• Pull the switch (Fig. 47) upwards:
The red indicator light in the switch is illuminated
–
Damping is engaged. Do not actuate the loader lift arm,
bucket or attachment control.
• Push the switch (Fig. 47) downwards:
The red indicator light in the switch goes off
–
Damping is disengaged. Loader controls can be actu-
ated.
