O P E R ATIN G A N D O PE R AT I O N
93
W L 3 0
Fig. 36
Depressurized
return line
Depressurized return line
For some attachments, a depressurized return line is re-
quired. The connection for the depressurized return line
is located on the front left of the load arm (Fig. 36). The
connection is designed in such a way that it is not possible
to confuse it with the normal connections for the optional
hydraulics.
