B A S I C S A F E T Y I N S T R U C T I O N S
40
2.8.7 Loader lift arm locking system
Apply the locking system for the loader lift arm by shifting
the lever located to the right of the operator’s seat Item 1
(Fig. 9).
•
Push the switching control rearward toward the seat
frame:
– the locking system is now on.
•
Pull the switching control forward away from the seat
frame:
– the locking system is now off.
CAUTION
Possibility of inadvertent loader lift arm activation.
Inadvertent activation can result in the loader arms
dropping causing the bucket or attachment to en-
gage the road surface. This can result in loss of
machine control with possible injury to the operator
and other work site persons.
►
Always lock the loader lift arm control to prevent
inadvertent activation during travel.
► The operator shall not leave the operator seat
until the loader arms and attachment have been
lowered to and are resting on the ground.
The loader lift arm can be secured against uninten-
tional operation by means of a locking mechanism.
If you have switched on the locking mechanism, the
loader lift arms will not move if the loader controls
are moved. The fact that the loader lift arm is locked
is not shown via indicator lights, but instead can be
seen from the position of the switching lever (Fig. 9).
Fig. 9
Lever for the locking
mechanism of the
Loader lift arm
1
