S E R V I C I N G A N D I N S PE C T I O N
150
10.3 Lubrication schedule
Lubricate all the points of lubrication daily with water-resistant multi-purpose grease. Lubricate all other moving parts
such as the handbrake lever, foot pedals, cables, etc. using the oil can.
Fig. 61
Points of lubrication
1 2 3 4 5 6 7 8 9 10 11 12 13 14
15 16 17 18 19 20 21 22 23 24 25
