O P E R ATIN G A N D O PE R AT I O N
71
W L 3 0
Push the lever away from the operator (position 1):
The right turn signal is activated.
Pull the lever towards the operator (position 2):
The left turn signal is activated.
Rotate the lever toward the operator:
The parking light switches on.
Continue rotating the lever toward the operator:
The driving light switches on.
Push the lever upwards (position 3):
The low beam switches on.
Push the lever downwards (position 4):
The high beam switches on.
Press the horn symbol (5):
The forward warning device is activated.
Fig. 24
Lighting / forward
warning device
1
2
3
4
5
