O P E R ATIN G A N D O PE R AT I O N
67
W L 3 0
2. Weight adjustment:
Adjust the weight while sitting in the seat by turning the
weight adjustment handle. The weight is set correctly if the
height position that has been set via the height adjustment
handle can be seen in the view window Item 2a. The middle
position of the spring‘s range for the respective height set-
ting will be indicated.
3. Backrest adjustment:
Adjust the backrest via the locking lever. The locking lever
should lock in the desired position. The backrest should not
move again after it has been locked in place.
4. Lengthwise adjustment
Adjust the length setting by pulling the locking lever up-
wards. After you have made the adjustment, the locking
lever should lock in the desired position. The operator‘s seat
should not move again after it has been locked in place.
5.1.6 Seat belt
WARNING
Personal injury hazard.
Not wearing the seat belt, or operating with a dam-
aged seat belt, can result in injury to the operator.
►
To operate the Wheel Loader, you must be
seated in the operator’s seat and the seat belt
must be properly fastened.
► Make sure seat belt and buckle stay clean.
►
Before operation check function of seat belt
and buckle.
►
Replace the belt or buckle immediately if they
are damaged.
►
Do not operate the machine if the seat belt is
damaged or not functioning correctly.
