T O W I N G A N D T R A N S P OR T I N G
118
6.2 Transporting Articulation frame lock
Personal injury hazard. Install the articulation frame
lock slowly and carefully to reduce the risk of injury.
The articulation frame lock is stored on the front
frame of the wheel loader as illustrated in Fig 53. It
is secured by two pins which are retained by spring
pins. To install the articulation frame lock, remove
the spring pin from the rear locking pin, pivot the
articulation frame lock down, and t over the front
locking pin. Secure with spring pin.
An articulation frame lock is provided as illustrated
in Fig 53 for preventing unintended frame articula-
tion during transport.
After securely tying the wheel loader to the plat-
form of the transport vehicle with OSHA or DOT
rated devices for the wheel loader mass, install the
articulation joint lock as shown in Fig 53.
Reverse the procedure at the point the wheel loader
is to be unloaded from the transport.
Load and transport the loader only according to
DOT safety regulations.
Only experienced, trained specialized personnel
may load and transport the loader.
