O P E R ATIN G A N D O PE R AT I O N
83
W L 3 0
Changing speeds
The loader has an overdrive and a crawler gear. Use the
button item 2 (Fig. 31) to shift the loader‘s gears. After start-
ing the engine, overdrive is automatically activated.
• Press the button:
– The loader shifts from overdrive to crawler gear.
Indicator light »9« (Fig. 13 ,page 50) lights up.
• Press the button again:
– The loader shifts from crawler gear to overdrive.
Indicator light »18« (Fig. 13 ,page 52) lights up.
Fig. 31
Changing direction
1
2
12 V
2
1
