O P E R ATIN G A N D O PE R AT I O N
112
Fig. 48
Optional hydraulics
control lever
Optional hydraulics control activation
This function allows you to actuate optional hydraulic con-
nections. This function is necessary if the standard hydraulic
connections do not sufce for certain attachments.
This feature is activated by moving the control lever adjacent
to the right side of the operator’s seat (Fig. 48).
• Move the control lever to the left:
–
The left-hand connection is for the pressure side, the
right-hand is for the return line.
• Move the control lever to the right:
– The right-hand connection is for the pressure side, the
left-hand is for the return line.
