S E R V I C I N G A N D I N S PE C T I O N
202
10.7.11 Servicing the electrical system
WARNING
Electric shock hazard.
Always disconnect the battery before working
on the electrical system if tools, spare parts, etc.
with electrical components or contacts could
touch it.
Electric shock and burn hazards.
Do not clean sensitive electrical components
(instrument panel, alternator, compact plug,
multi-function lever, etc.) with a high-pressure
cleaner.
Do not touch incandescent lamps and headlight
reectors with your ngers if the bulbs have
been illuminated.
Have malfunctions in the electrical system cor-
rected by trained specialized personnel.
Fuse allocation
The electrical circuits of the wheel loader are fused to pre-
vent damage from short circuits and malfunctions. The fuses
are located in box 1 and 2 near the starting key receptacle
on the right side of the steering column. The second location
box 3 is on the right hand side of the cab next to the wiper
and light control switches.
NOTICE:
If an electrical device fails to respond to a control
movement, stop the wheel loader as if stopping at
the end of a work shift and check the fuse for that
circuit. If the fuse has failed, determine the cause
of failure and repair the cause.
Insert a new fuse of the specied rating and return
to work.
Do not continue work with a failed fuse.
Do not install a fuse with a higher rated capacity
than the failed fuse. This can result in serious dam-
age to the electrical circuit.
