O P E R ATIN G A N D O PE R AT I O N
72
5.2.2 Wipers and windshield washer system
The wipers and windshield washer system are switched
on/off using the rocker switches in the cab roof on the right
next to the operator’s seat Item 4 and 5 (Fig. 25).
Front window:
• Put the rocker switch Item 4 in position 1:
– The windshield wiper switches on.
• Put the rocker switch Item 4 in position 2:
– The front windshield washer system switches on.
• Put the rocker switch Item 4 in position 0:
–
The windshield wipers and windshield washer system
switch off.
Rear window:
• Put the rocker switch Item 5 in position 1:
– The back wiper switches on.
• Put the rocker switch Item 5 in position 2:
– The back washer system switches on.
• Put the rocker switch Item 5 in position 0:
–
The windshield wiper and windshield washer system
switch off.
Fig. 25
Switches for wind-
shield wipers
4 5 6 7 8 9
