S E R V I C I N G A N D I N S PE C T I O N
151
W L 3 0
Item Point of lubrication Nipples
13
Small tie rod, rear [1]
14
Small tie rod, front [1]
15
Cab tilting hinge, rear [1]
16
Drive shaft, rear [1]
17
Steering cylinder, rear (remote lubrication) [1]
18
Cab tilting hinge, front [1]
19
Center pivot bearing, bottom [1]
20
Steering cylinder, front [1]
21
Drive shaft, front [1]
22
Large tie rod, rear [1]
23
Bearing for small reversing lever [1]
24
Pivot point of tool attachment [2]
25
Tool locking bolts [2]
Item Point of lubrication Nipples
1
Engine enclosure hinges [2]
2
Door hinges [4]
3
Brake pedal bearing (in the cab) [1]
Brake lever bearing (under the cab) [1]
4
Accelerator (in the cab) [1]
5
Center pivot bearing, top [2]
6
Arm, top [2]
7
Lifting cylinder, rear [2]
8
Tipping cylinder, rear [1]
9
Lifting cylinder, front [2]
10
Bearing for large reversing lever [1]
11
Tipping cylinder, front [1]
12
Large tie rod, front [1]
