TECHNICAL DATA
47
W L 3 0
*In the event of deviating tires or reversed wheel rims the dimensions will change
Dimensions with 31x15,5-15EM tires
Item Designation Value
A Overall length with standard
shovel
4554 mm 179.29 inch
A‘ Overall length without shovel 3748 mm 147.56 inch
B Axle center to shovel pivot-
point
722 mm 28.43 inch
C Wheelbase 1732 mm 68.19 inch
D Rear overhang 1179 mm 46.42 inch
E Overhead loading height* 2990 mm 117.72 inch
F Max. height of shovel pivot
point*
3209 mm 126.33 inch
G Height of seat* 1254 mm 49.37 inch
H Max. dumping height* 2416 mm 95.12 inch
I Scraping depth* 26 mm 1.02 inch
K Reach at H* 334 mm 13.15 inch
L Height to top of cab* 2251 mm 88.62 inch
Item Designation Value
M Total working height* 4070 mm 160.24 inch
N Max. dumping angle at max.
lift height
43°
O Reverse roll angle on ground 43°
P Reverse roll angle at max. lift 50°
Q Inside turning radius* 1413 mm 55.63 inch
R Overall width* 1345 mm 52.95 inch
S Radius at outer edge* 2793 mm 109.96 inch
T Ground clearance* 261 mm 10.28 inch
U Turn angle 45°
V Width across cab 870 mm 34.25 inch
W Track width* 941 mm 37.05 inch
Z Maximum turning radius
(depends on shovel width)
3186 mm 125.43 inch
