Data sheet
28.03.2022 109 / 112
10 Data sheet
Dimensions and weight
Term Value Unit
Weight 5.8 kg
Width 149 mm
Height with closed bell cover 243 mm
Height with open bell cover 370 mm
Depth 305 mm
Technical data
Term Value Unit
Vacuum range -0.1 to -0.8* bar
Pressure range 0.1 to 10 bar
Accuracy of the test pressure ± 80 mbar
* maximum vacuum that can be generated depends on the atmospheric
pressure.
Connection values for
power supply
Term Value Unit
Mains voltage 100 to 240 VAC
Mains frequency 50 / 60 Hz
Power supply unit output
values
Term Value Unit
Voltage 12 VDC
Maximum current consumption 5.0 A
Maximum power consumption 60 W
Standby power consumption typically 2.8 W
Compressed-air connection
Term Value Unit
Maximum feed-in pressure 12 bar
Feed-in pressure for operation of the device
with maximum
output
11 bar
Compressed-air consumption per pressure
test
10 l/test
Compressed-air consumption per vacuum
test
40 l/test
Compressed air quality Dry and oil-
free
