Manual 37128A GCP-20 Series - Genset Control

Examples:

• GCP-2245B/LSX (GCP-22 with 400 Vac and ../5 A measuring inputs, Package LSX [2 breaker logic; analog

controller n/f, V, P, Q; real power set point 0/4 to 20mA; 3 analog inputs, 2 analog outputs])

• GCP-2115B/LS (GCP-21 with 120 Vac and ../5 A measuring inputs, Package LS [1 breaker logic; discrete

raise/lower n/f, V, P, Q])

Intended Use The control unit must only be operated as described in this manual. The prerequisite for a proper

and safe operation of the product is correct transportation, storage, and installation as well as careful operation

and maintenance.

NOTE

This manual has been developed for a unit fitted with all available options. Inputs/outputs, functions,

configuration screens and other details described, which do not exist on your unit may be ignored.

The present manual has been prepared to enable the installation and commissioning of the unit. Be-

cause of the large variety of parameter settings, it is not possible to cover every possible combination.

The manual is therefore only a guide. In case of incorrect entries or a total loss of functions, the default

settings can be taken from the enclosed list of parameters.

Woodward GCP-20 Series User Manual
