Appendix F.
List of Parameters
Unit number P/N _____________________________ Rev _______________________________
Version GCP- _________________________________________________________________
Project _____________________________________________________________________
Serial number S/N _______________ Date ______________________________
Option
Parameter
1. Line Text 2. Line
Adjustment range Standard setting Customer settings
Code
level
software version
- V x.xxxx - - 0
Service-Display
ON/OFF ON  on  off  on  off 0
enter code number
0 to 9999 XXXX 0
GENERATOR AND NETWORK CONFIGURATION
Configure Base?
YES/NO YES  Y  N  Y  N 2
Generator-number
1 to 8 1 2
load conf. direct
YES/NO NO  Y  N  Y  N 2
Generator freq. f set
40.0 to 70.0 Hz 50.0 Hz 2
Rated frequency generator
50.0/60.0 Hz 50.0 Hz 2
Gen.volt.transf. secondary
50 to 125
200 to 440 V
400 V 2
Gen.volt.transf. primary
0.050 to 65.000/
0.200 to 65.000 kV
0.400 kV 2
Bus.volt.transf. secondary
50 to 125
200 to 440 V
400 V 2
Bus.volt.transf. primary
0.050 to 65.000/
0.200 to 65.000 kV
0.400 kV 2
mains volt.trans secondary
50 to 125
200 to 440 V
400 V 2
mains volt.trans primary
0.050 to 65.000/
0.200 to 65.000 kV
0.400 kV 2
Gen. voltage U set
25 to 140/50 to 500 V 100/400 V 2
Current transf.
G
enerator
10 to 7,000/x A 500/x A 2
Rated current Gen.
10 to 2,999 A 300 A 2
Power measuring Gen.
single-/three-phase threephase  s  t  s  t 2
Rated power Gen.
5 to 9,999
5 to 6,900 kW
200 kW 2
Current transf. Mains
10 to 7,000/x A 500/x A 2
In20
analog in Pmains
0 to 20/4 to 20 mA 4 to 20 mA 2
..
analog in Pmains 0%
+/- 0 to 9.99
+/- 0 to 6.9 kW
-200 kW 2
In20
analog in Pmains 100%
+/- 0 to 9.99
+/- 0 to 6.9 kW
200 kW 2
Define level 1 code
0 to 9999 0001 2
Define level 2 code
0 to 9999 0002 2
