Woodward GCP-20 Series User Manual

Manual 37128A GCP-20 Series - Genset Control
Page 74/190 © Woodward
Parameter 10
Bus.volt.transf.
secondary 000V
Secondary busbar voltage transformer [1] 50 to 125 V; [4] 200 to 440 V
L This value corresponds to the secondary voltages of the PTs, which are di-
rectly connected to the control.
The secondary voltage is set here in V. This parameter is used to display the secon-
dary voltages on the control unit screen.
Parameter 11
Bus.volt.transf.
primary 00.000kV
Primary busbar voltage transformer [1] 0.050 to 65.000 kV; [4] 0.200 to 65.000 kV
L This value corresponds to the primary voltages of the PTs.
The primary voltage is set here in kV. This parameter is used to display the primary
voltages on the control unit screen. In the case of measured voltages of 100 V
without a measurement transducer, 00.100 kV must be set here; for 400 V =
00.400 kV.
WARNING
If the value of the following parameter is changed, the values of the following parameters have to be
checked:
• Threshold mains overvoltage
• Threshold mains undervoltage
Parameter 12
mains volt.trans
secondary 000V
Secondary mains voltage transformer [1] 50 to 125 V; [4] 200 to 440 V
L This value corresponds to the secondary voltages of the PTs, which are di-
rectly connected to the control.
The secondary voltage is set here in V. This parameter is used to display the secon-
dary voltages on the control unit screen.
Parameter 13
mains volt.trans
primary 00.000kV
Primary mains voltage transformer [1] 0.050 to 65.000 kV; [4] 0.200 to 65.000 kV
L This value corresponds to the primary voltages of the PTs.
The primary voltage is set here in kV. This parameter is used to display the primary
voltages on the control unit screen. In the case of measured voltages of 100 V
without a measurement transducer 00.100 kV must be set here, for 400 V =
00.400 kV.
Rated Voltage Values
Parameter 14
Gen.voltage
U set 000V
Generator set point voltage [1] 50 to 140 V; [4] 50 to 500 V
L This value corresponds to the secondary voltages of the PTs, which are di-
rectly connected to the control.
This value of the voltage specifies the set point of the generator voltage for no-load
and isolated operation.
